| Horizontal inserting width: A |
mm |
Model CGJ450–2 |
| |
|
120~700 / single–position |
| |
|
120~320 / double–position |
| |
|
Model CGJ450–3 |
| |
|
120~900 / single–position |
| |
|
120~420 / double–position |
| Lengthways sheets length: B |
mm |
120~450 |
| Clapboard Height: C |
mm |
80~300 |
| Lengthways clapboard distance: D |
mm |
20~250 |
| Horizontal clapboard distance: E |
mm |
Model CGJ450–2 |
| |
|
50~115 / 2 inserting / double–position |
| |
|
50~230 / 2 inserting / single–position |
| |
|
50~140 / 4 inserting / single–position |
| |
|
Model CGJ450–3 |
| |
|
50~110 / 3 inserting / double–position |
| |
|
50~225 / 3 inserting / single–position |
| |
|
50~128 / 6 inserting / single–position |
| Carton inserting mouth width: F |
mm |
> board thickness |
| Carton thickness: G |
mm |
1.5 ~ 8 mm |
